MAIN CHARACTERISTICS

BUILDER: HARGRAVE SUPER YACHTS

ACCOMODATION 10 GUESTS + 7 CREW

CLASSIFICATION Rina Pleasure Yachts
C Ì HULL oMach Y UNRESTRICTED NAVIGATION

LENGTH OVER ALL 36 meters / 118.33 ft

LENGTH WATER LINE 31.75 meters / 104.2 ft

BEAM MAX 7.92 meters / 26 ft

DRAFT (max) 2 meters / 6.5 ft

DISPLACEMENT (Light Ship) 170 Tonnes

DISPLACEMENT (Fully loaded) 210 Tonnes

GROSS TONNAGE 323 GT (Approx.)

TOP SPEED 20 Knots (With 2x 2400HP C 32’s Top Speed 24kts)

PROPULSION

MAIN ENGINES 2 x CAT C32 1900HP @ 2300 Rpm

GEARBOX ZF5000 SERIES 2,98:1

ENGINE CONTROL GLENDINING ( 1 main + 3 remote station)

GENERATORS Caterpillar 75 KW
Caterpillar 75 KW

SHAFT PROPELLER CJR (UK) 4,5” AQUAMET 22HS Shaft / 5 Blades Class S Propellers

ELECTRIC SYSTEM 120 / 208 VAC 3P 60Hz Main Service

24VDC Service and Engine Start System

TANK CAPACITY

Diesel Oil : 31.750 Lt / 8.350 Gallons

Fresh Water : 4.000 Lt / 1.000 Gallons

Black Water : 2.000 Lt / 500 Gallons

GreyWater : 2.700 Lt / 700 Gallons

BUILD / CONSTRUCTION

HULL / SUPERSTRUCTURE : CARBON RAINFORCED E-GLASS - EPOXY COMPOSITE SANDWICH

OPEN DECK : HANDLAID BURMESE / MYANMAR TEAK OR NON SKID PAINT

PAINT SYSTEM : AWLGRIP

MASTER EQUIPMENT LIST

Airhorn Kahlenberg

Anchor winch and Capstans (x2 )Maxwell VWC8000 Hyd. Windlass, VC800 Capstans

Windscreen Wipers Speich

Alarm & Monitoring system Beijer - Wago

Anchor and Chain (x2) 200kg 316L S.S. Pool Anchor, (x2) 110m (360 ft) 16mm

Grade 2 Studlink Chain

Audio / Video Crestron

Batteries and chargers Victron

ER Venilation Delta T System

Bow thrusters Naiad 65kW Bow thruster

Stabilizer Naiad 525 At Rest Stabilizer with 22kW Power Pack

Fuel oil filters Racor

HVAC NorthernLights Technicold

Chiller assembly x3 H/ 10 TON/ TOTAL: 360,000 BTU

Steering System Data Hydraulics AC /DC Steering

Insulation Unifrax B15 Engine room and B0 Galley insulation

Rockwool Thermal cabin insulation

Navigation and communication equipment GARMIN

Pumps HeadHunter and Depco

Sewage treatment Headhunter

Toilet system Headhunter

DECK EQUIPMENT

SWIM LADDER 316L Stainles Steel

CRANE Hydraulic Deck Crane

HANDRAILS High Grade 316L S.Steel

PANTOGRAPH DOORS (x4) Pantograph Door

SLIDING DOORS Electric Operated main and upper saloon doors

WATERTIGHT DOORS AND DECK HATCHES Watertight Deck Hatches and Engine room WT Fire Doors

AFT BEACH SHELL DOOR Hydraulic Actuator Operated Carbon Reiforced Composite

Watertight Door

SAFETY EQUIPMENT

LIFE RAFTS 2 x 16 Persons

FIRE PROTECTION FirePro Engine Room Fire Protection

FIRE & GENERAL ALARM SYSTEM TYCO
